    UP-2001 Versatile Single Column Universal Testing Machine AC110V-220V

    UP-2001 Versatile Single Column Tensile Testing Machine
    High-precision tensile strength testing equipment with simple structure and convenient operation, designed for testing material strength across various industries including paper, plastic, rubber, wire, textiles, packaging, and building materials.
    Design Standards
    ASTM D903, GB/T2790/2791/2792, CNS11888, JIS K6854, PSTC7, GB/T 453, ASTM E4, ASTM D1876, ASTM D638, ASTM D412, ASTM F2256, EN1719, EN 1939, ISO 11339, ISO 36, EN 1465, ISO 13007, ISO 4587, ASTM C663, ASTM D1335, ASTM F88, ASTM D882, ASTM D5034, ASTM F2458, EN 1465, ISO 2411, ISO 4587, ISO/TS 11405, ASTM D3330, FINAT
    Technical Specifications
    Capacity5, 10, 20, 50, 100, 200KG Optional
    Test Accuracy±1%
    Display ModeComputer Controlled
    Unit ChangeKg, lb, N
    Data Sampling Frequency200 times/sec
    ResolutionMax load 1/±25000, no internal or external grading
    Load CellBasic configuration: tension and pressure sensors
    Effective Test Width150mm
    Effective Test Height800mm
    Test Speed Range50-300mm/min
    Displacement Measurement Accuracy±1%
    Breakpoint Ratio Setting0-99%
    Safety DevicesUp and down travel limit device, overload protection, emergency shutdown
    FixtureTensile/compression each 1 set
    Machine Size500×400×1300mm
    Machine WeightApproximately 70 Kg
    Product Images
    Our Service Process
    • Customer Inquiry: Technical consultation and product recommendation with competitive pricing
    • Customization: Detailed drawings and specifications confirmation for custom requirements
    • Production & Delivery: Quality-controlled manufacturing with progress updates and calibration services
    • Installation & Support: Field installation and comprehensive after-sales service
    Frequently Asked Questions
    Are you a Manufacturer? Do you offer after-sales service? How can I ask for that? And how about the warranty?
    Yes, we are professional manufacturers of testing equipment. Every machine includes a 12-month warranty with free maintenance. Extended warranty available for sea transportation. Technical support provided via email, phone, or video chat with solutions offered within 24-48 hours.
    What about the delivery term?
    Standard machines: 3-7 working days if in stock, 15-20 working days if not in stock. Urgent orders receive special arrangements.
    Do you accept customization services? Can I have my logo on the machine?
    Yes, we offer both standard and customized machines according to your requirements, including OEM and ODM services with logo placement.
    How can I install and use the machine?
    We provide English operation manuals and videos. Most machines are shipped fully assembled - simply connect power and begin operation. On-site installation assistance available when necessary.
